Description
21 volt AC turntable motor
Part number: 6549W1S021B
The microwave turntable motor is a synchronous motor so the turntable can turn is either direction. The microwave turntable motor uses a built in gearbox to drive the turntable tray via the microwave turntable coupling.
21volt AC turntable motor suitable for some Panasonic microwave ovens.
Type GM-16-2F302 turntable motor.
Dimensions:
D shaped drive shaft
Shaft length 11 mm
Shaft maximum diameter 7 mm
Diameter to flat side 5 mm.
Terminal width 4.8 mm.
