Description
240 volt turntable motor for Bosch microwave oven,
Part number Z63266S30XP.
Equivalent to the following turntable motors:
3966310100, 351200300001, Z63269W00XP, Z63269P00HP, Z6326BS20BP, Z63266S30XP, M77303, Q15297, Z63266530XP ,11002014A00325
Specifications:
Voltage = 240 volts AC 50-60 Hz
Rotation speed = 5-6 RPM
D shaped cross section drive shaft
Shaft length = 13 mm
Shaft maximum diameter = 7 mm
Diameter to flat side 7 mm.
Terminal width 4.8 mm.240 volt AC 5/6 RPM Panasonic turntable motor.
The microwave turntable motor is a synchronous motor so the turntable can turn is either direction. The microwave turntable motor uses a built in gearbox to drive the turntable tray via the microwave turntable coupling.
